UHF RFID floor mat antenna

This floor mat is an alternative solution to the use of antennas of the UHF system.

Depending on your discipline and the configuration of the environment of your finish line or passage, it may be practical or essential to use this floor mat on the ground.

A combination of 2 antennas with 2 floor mats is an excellent compromise frequently used with this type of system.

€500.00 tax excl.

€600.00
Tax included
2 years warranty
Fast delivery with Chronopost
Return within 14 days

Description

Very strong, it can support the passage of a truck.

Caractéristiques techniques :

  • Size : 1200 * 500 * 40 mm
  • Frequency Range ISM 840 ~ 960 MHz
  • Read range 1-3m (depend on reader/tag and install)
  • Gain : 9 dBi
  • Weight : 3,8 kg
  • Horizontal -3dB beam width 80°
  • Vertical -3dB beam width 40°
  • Lightning Protection DC to ground
  • Working Temp - 40 ~ 70°C
  • Waterproof level : IP65

Technical specifications

ITSUHFFA
80 cm
125 cm
20 cm
5 kg
